Technical Specifications

1)IR day and night vision for recording

2) Recording resolution:

1280x960

720x480

640x480

4) Repeat storage by section: 2/5/15 minutes or off

5) Power source: Built-in rechargeable battery or 12V/24V Car Charger

6) Supports SD/MMC card ( From 1GB up to 32GB)

7) Microphone: can record sound

8) Interface: USB2.0

Setting the functions:

Turn on the DVR and press to enter into setting interface.Menu Button. Confirm by and select by for the following setting. Press again to exit after finished.

1.Movie Size: Select[1280x960, 720x480, 640x480]

2 Audio Recording. :Select On or Off

3 Volume:From 0 to7

4 Motion Detect: Select On or Off

6 Recording time:select [2/5/15]minute to decide how many time will be storage per one section

7 Date Stamp: Select [Date &TimeStamp]or [No Stamp]

8 Date/Time: Setcorrect recording Dateand time.

9 Language: Select [English/Chinese/Russian]

10 LightFrequency: set [50/60Hz].

11 Restore Default:. Select[ Yes]or [No].

12 Version:. Show thesoftware versionNumber.

120 degree Wide Angle
6 IR LED lights ,Better Night version
(6 IR lights ,better night vision ,wide 120 degree)
(USB 2.0 ,Can transferr the video to your PC )
SD card is not included ,it can support Max 32GB memory card

Note: 1) Please insert the SD/ MMC card before recording.

2) Please adjust the time display before recording. If not set a time, the DVR cannotrecord.

3) This DVR records in cycle if you choose 2/5/15 minutes as storage time.When the storage medium is full, it will record from the beginning again and erase over the previously recorded material automatically.It will have 3 seconds paus time,and namely the contents in the 3 seconds will not recorded.

4) Because the DVR is DC5V input,please use the attached car charger. It have adaptor 12V/24V transfers to 5V already.

5) Whenyou cannot stop recording by pressing REC button, please check if you have selected the is.Montion Detect ON. If yes,please select.OFF

What is included:

Camcorder

Manual Li-ion battery

Mount

USBCable

Car Charger (Includethe adpator 12V/24Vtransfers to 5V)
