Описание продуктов :

    All-in-one 3.5" LCD Monitor CCTV Camera PTZ Test Tester
    The CCTV testerPRO� JE-T894 is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video signal, controlling PTZ, searching the PTZ device ID address, generating images, capturing data of RS485 and testing LAN cable etc. With it, you can do easy and simply on installing and maintaining the CCTV system, it also will improve work efficiency and get the labor cost down.

    1, Video Test

    2, PTZ controller

    3, Video signal Level Test

    4, Color bar Generator

    3.5" 960(H) X 240(V) high resolution TFT LCD screen, display video input signal

    As a controller, it possess full function to Control the PTZ camera, configure PTZ parameter: protocol, baud rate and ID address, pan/tilt speed, setup and call preset position

    Adjust LCD Brightness, Contrast, Color saturation, Video Format and Video level testing. Output or receive standard color bar signal, testing monitor, cable or other equipment.
    5, UTP Cable test 6, RS485 Data Monitor 7, Address search 8, Digital multimeter
    Test LAN or telephone cable. the connecting condition and sequence of wires will be displayed, as well as the serial number of the cable tester kit. Capture the protocol from the controlling system and display the command and data. Search The PTZ camera ID Digital Multimeter performs AC/DC Voltage, AC/DC Current, Resistance, Continuity, Capacitance and Diode test, Auto/ Manual Range, Data hold, Relative measuring

    9, Audio Test

    10, DC12V 1A Output

    It built-in speaker for audio test Power the camera with DC12V(1A) power output from the tester. It is helpful for demo and testing where there is no power supply available
    CCTV TesterPRO
    Video Test Signal mode PAL/ NTSC auto adapt
    Display 3.5 inch digital TFT LCD, 960 X 240 resolution
    LCD adjustment Brightness, Contrast, Saturation adjustable
    Video In/ Out 1CH BNC input & 1CH BNC output
    Video output mode 1.0Vp-p
    Video Level Test Level Test Video signals measured in IRE or mV
    PTZ Controller Communication RS232, RS422 simplex and RS485
    Protocol Compatible with more then 20 protocls such as Pelco D/P, Samsung, Panasonic, Lilin, Yaan... etc.
    Baud Rate

    150, 300, 600,1200,2400, 4800, 9600, 18200bps

    Video Signal Generation Color bar generation

    Output one channel PAL/NTSC color bar video signal for test monitor or video cable

    UTP cable test UTP cable test

    Test UTP cable connection status and display in the screen, Read the number of the test box

    DC Power Output DC power output

    Output DC12v 1A power for the camera

    Audio Test Audio test

    Test the pickup and other audio equipments on the front-end

    RS485 data analyst Data Monitor

    Captures and analyzes the command data from controller device

    Power Power Adapter

    AC110~240V/ DC12V 2A

    Battery

    Built in 3.7V ,3000mAH Li-ion batteries

    Rechargeable

    After charging 3-4 hours, working time lasts 12 hours

    General Working Temperature

    -10 ~ +50

    working Humidity

    30 ~ 90%

    Dimension/ Weight

    176mm X 94mm X 36mm /340g

    Digital Multimeter
    Counts: -6600 ~ +6600, Conversion rate: 3 times/s, Current modes for clamp meter with ZERO function
    DC Voltage Rang Accuracy Resolution
    660mV (manual range) +- (0.3%+4) 0.1mV
    6.6V 1mV
    66V 10mV
    660V 100mV
    AC Voltage Rang Accuracy Resolution
    660mV (manual range) +- (1.5%+6) 0.1mV
    6.6V +- (0.8%+6) 1mV
    66V 10mV
    660V 100mV
    DC/ AC Current Rang Accuracy Resolution
    6.6mA +- (0.5%+3) 1uA
    66mA 10uA
    660mA 100uA
    10A +- (1%+5) 10mA
    Resistance Rang Accuracy Resolution
    660? +- (0.8%+3) 0.1?
    6.6K? +- (0.8%+2) 1?
    66K? 10?
    660K? 100?
    6.6M? 1K?
    66M? +- (1.2%+5) 10k?
    Continuity Rang Function
    ))) Built-in buzzer will be sound, if resistance is low than 50?
    Diode Resolution Function
    1mV Display: read approximate forward voltage of diode
    Capacitance Rang Accuracy Resolution
    6.6nF +- (0.5%+20) 1pF
    66nF +- (3.5%+8) 10pF
    660nF 100pF
    6.6?F 1nF
    66?F 10nF
    660?F +- (5%+8) 100nF
    6.6mF 1?f
    66mF 10?F

    Video cable

    1pc

    RS485 cable 1pc
    DC Output cable 1pc
    Multimeter cable 2pcs
    Audio cable 1pc
    LAN cable test 1pc
    Rechargeable Li-ion batteries 1pc
    safety belt 1pc
    Robber housing 1pc
    Tester (Model: JE-T894) 1pc
